Focal Length: 8mm ~ 96mm (12x) Iris Range: F2.0 ~ T400 (Equivalent to F400)
Operation Iris: Auto(DC Type) Focus: Motor Drive Zoom: Motor Drive
Angle of View (H x V) 1/2 Wide 43°36′ × 33°24′ 1/3 Tele 3°49′ × 2°52′
1/3 Wide 33°24′ × 25°22′ 1/4 Tele 2°52′ × 2°09′
1/4 Wide 25°22′ × 19°09′ 1/4 Tele 2°09′ × 1°37′
Focusing Range (From Front Of The Lens) ∞ ~ 1.3m
Object Dimensions at M.O.D. (H × V) 1/2˝ Wide 1003mm × 753mm 1/3˝ Tele 84mm × 63mm
1/3˝ Wide 752mm × 565mm 1/4˝ Tele 63mm × 47mm
1/4˝ Wide 564mm × 424mm 1/4˝ Tele 47mm × 35mm
Back Focal Distance(in air): 16.22mm Exit Pupil Position (From Image Plane): -51mm
Filter Thread: M55 X 0.75 Mount: CS Mount Mass: 330g
