Focal Length: 7.3mm ~ 117mm (16x) Iris Range: F1.9 ~ F16 * Close
Operation Iris: Motor Drive Focus: Motor Drive Zoom: Motor Drive
Angle of View (H x V) 1/2 Wide 47°20′ × 36°24′ 1/2 Tele 3°08′ × 2°21′
1/3 Wide 36°24′ × 27°42 1/3 Tele 2°21′ × 1°46′
1/4 Wide 27°42′ × 20°57 1/4 Tele 1°46′ × 1°19′
Focusing Range (From Front Of The Lens) ∞ ~ 1m
Object Dimensions at M.O.D. (H × V) 1/2˝ Wide 823mm × 617mm 1/2˝ Tele 51mm × 39mm
1/3˝ Wide 617mm × 464mm 1/3˝ Tele 39mm × 29mm
1/4˝ Wide 464mm × 348mm 1/4˝ Tele 29mm × 22mm
Back Focal Distance(in air): 19.5mm Exit Pupil Position (From Image Plane): 220mm
Filter Thread: M62 X 0.75 Mount: C Mount Mass: 900g
