pdf BigRep One V3.pdf

50.000,00€ + VAT Request lower price Interest form

BigRep ΟΝΕ v3 is the most advanced large scale 3d printer.The driving force behind the BigRep ONE v3 remains unchanged: to make large-scale 3d printing affordable to more users such as engineers,researchers and artists.
BigRep ONE v3 give us the capability to create big prints, fast and accurate up to 150microns layer resolution (0.5 mm nozzle optional).

Features:

1. Open format frame construction ensures the best possible view for monitoring the progress,enclosed moving parts and integrated sensors ensure safety,precision and user friendliness.
2. Two modular and independent print heads, developed by BigReps in-house team optimized for large scale printing projects .
3. Automatic leveling print bed can be leveled quickly and effortlessly before a new project,reducing prep time considerably.
4. The BigRep ΟΝΕ v3 features a build volume over one cubic meter providing the largest FFF build volume currently on the international market.
5. The spool holder can hold several spools up to 10kg and a run-out detection system notifies the user when the spool is about to end.Also, there is an enclosure for the filament,available as part of the Advanced Kit.
6. The BigRep ONE v3 is equiped with an integrated control unit and touch panel.The in-house designed graphical user interface allows you to conduct all necessary work steps and operations easily and intuitively.Additionally,a VPN tunnel enables BigReps service team to perform service and maintenance.
7. The printing speed can now be increased to 400% with the optional Perfomance kit, making the BigRep ONE v3 the fastest large-scale 3D printer in the world.

Also known as

One V
OneV3
(One V3)

  • 3D Printing Technology : Fused deposition modeling (FDM)

  • Volume (cm3) : From 701 to 1.000 cm3

  • Layer Resolution (μm) : From 900μm to 150μm

  • Extruder : 2

  • Nozzle diameter : Bigger than 500 μm

  • Printing Material ABS : Yes

  • Printing Material PLA : Yes

  • Printing Material PVA : Yes

  • Printing Material Nylon : Yes

  • Filament diameter : 2.85mm

  • Heated Bed : Yes

  • Chamber : Open type

  • Printing Material PETG : Yes

  • Printing Material HT-Pro : Yes

BigRep IndustrialFilament - Pro HT - Schwarz- 2,3kg
Pro HT Industrial print filament high temperatur color black (other sizes and colors on request)
Starting price
129,95€
BigRep IndustrialFilament - Pro HT - Schwarz - 4,5kg
Pro HT Industrial print filament high temperatur color black (other sizes and colors on request)
Starting price
263,95€
BigRep IndustrialFilament - Pro HT - Schwarz - 8kg
Pro HT Industrial print filament high temperatur color black (other sizes and colors on request)
Starting price
419,95€
BigRep PLA-TrueBerlinColor Filament - Berliner Luft - 2,3 kg
PLA Standard print filament Color: white translucent Diameter: 2.85mm (other sizes and colors on request)
Starting price
64,95€
BigRep PLA-TrueBerlinColor Filament - Schwarzfahrer - 8 kg
PLA Standard print filament Color: black Diameter: 2.85mm (other sizes and colors on request)
Starting price
224,95€
BigRep PETG-TrueBerlinColor Filament - Berliner Wei-e Pur - 2,3kg
Print filament PETG, Color: transparent Diameter: 2.85mm (other sizes and colors on request)
Starting price
108,20€
BigRep PETG-TrueBerlinColor Filament - Berliner Wei-e Pur - 4,5kg
Print filament PETG, Color: transparent Diameter: 2.85mm (other sizes and colors on request)
Starting price
169,95€
BigRep PVA-TrueSupport -2,3kg
Professional PVA Support material, easy to remove easy soluble in water 100% ecologically biodegradable (other sizes on request)
Starting price
249,95€
BigRep PVA-TrueSupport - 4,5kg
Professional PVA Support material, easy to remove easy soluble in water 100% ecologically biodegradable (other sizes on request)
Starting price
447,95€
BigRep PVA-TrueSupport - 8kg
Professional PVA Support material, easy to remove easy soluble in water 100% ecologically biodegradable (other sizes on request)
Starting price
827,95€
BigRep Studio
3D printer (FFF) for large scale printings 500mm x 1000mm x 500mm
Starting price
31.900,00€
Prices without VAT
